Model | O.D | I.D | Length | Filtration surface(m2) |
LF-660*324 | Φ324mm | Φ213mm | 660mm | 9.4m2 |
LF-660*352 | Φ352mm | Φ241mm | 660mm | 9.4m2 |
LF-750*324 | Φ324mm | Φ213mm | 750mm | 10.7m2 |
LF-880*324 | Φ324mm | Φ213mm | 880mm | 12.5m2 |
LF-915*324 | Φ324mm | Φ213mm | 915mm | 13.0m2 |
Filter Material:
1. Base media: Spunbonded polyester
2. Operating efficiency: 99.9% on 1 micron
3. Washable: Several times
4. Maximum operating temperature: 200oF/93oC
5. Abrasion resistance: Excellent
6. Chemical tolerance: Excellent
7. Optional flame retardant media(FR): To order
Other composition:
1. Gasket: Neoprene rubber, good at absolute hermetic seal, improving the durability
and life.
2. Inside cage: Galvanized steel, to prevent corrosion.
3. Molded top: Available in a varitety of styles and sizes to fit a wide range of Tubesheet Holes.
4. Molded bottom: Helps resist abrasive wear at the bottom of the elements.
Applications:
1. Description: Excellent performance on moist, hygroscopic, or agglomerative dust.
2 Marktets: Thermal spray, welding, mining, chemical processing, metal buffing, pharmaceutical,cement, woodworking and etc.
3. Dust types: Fumed silica, metallic fume, metallurgical powders, and etc.
4. Available for collectors: SFF/XLC, SFFK, Torit DFT
5. Substitute: Donaldson, Nodic, BHA
Notes:
1. Optional construction and dimensions are available on all cartridges.
2. Please contact us to make optimal filtration solutions of your applications.
AAF Replacement Filters
125-1525856-001
125-1525856-002
134-1569656-001
134-1645571-001
135-1658301-001
135-1740703-001
135-1740729-001
135-1740745-001
135-1778505-001
164-6819-1
1658301-001
1662154
1740786-001
1830603-001
1835271-003
1835271-005
1835271-006
1835289-001
1835669-001
1835669-002
1835792-001
1835792-002
1845064-002
1845064-003
1846930-001
1846930-006
1846955-001
1846955-002
2441285-000
2441301-000
366-125-109
366-130-749
366-431-625
366-725-180
366-725-184
366-756-250
366-810-050
366-818-803 AAF
366-818-804 AAF
366-818-822 AAF
366-818-823
366-819-215 AAF
366-819-275 AAF
366-820-030 AAF
366-822-269 AAF
366-825-370 AAF
5239629 AAF
