Inexpensive 5 Micron Cartridge Filter with RO Plant Stainless Steel Filter Housing

Low price 5 Micron Cartridge Filter With RO Plant Cartridge FiltersThe security filter is most commonly used for treat water. The whole system adopts one set of stainless filter.There are 12 pieces of polypropylene in every 5μ Filter cartridges, filtering the vast majority of particles in theWater, which eases the load o

Featured Products

Low price 5 Micron Cartridge Filter With RO Plant
Low Price 5 Micron Cartridge Filter with RO Plant Stainless Steel Filters Housing

Cartridge Filters
The security filter is most commonly used for treat water. The whole system adopts one set of stainless filter.
There are 12 pieces of polypropylene in every 5μ Filter cartridges, filtering the vast majority of particles in the
Water, which eases the load of RO membrane. This process of filtration benefits to the filter cartridge and prolongs
Its lifetime in the system. This apparatus contains filtration component and stainless support layers. The support
Layer is made of stainless steel 304, with the advantages of compact structure, beautiful shape, high flux, good
Filtration accuracy and etc.
Low Price 5 Micron Cartridge Filter with RO Plant Stainless Steel Filters Housing
Stainless steel Bag Filter Housing
Low Price 5 Micron Cartridge Filter with RO Plant Stainless Steel Filters Housing

Technical parameters:
1. Design pressure: More than 0.6Mpa
2. Work pressure: 0.1-0.4MPa
3. Design temperature: Normal temperature
4. Sealing material: Butyl rubber, silicone, fluorine rubber standard, standard configuration is silica gel seal
5. Interface form: Threaded, bar clasp, GB standard flange
6. Applicable filter: Flat crush type PP great filter / 222 socket filter
7. Surface treatment: Mirror polishing, electrolytic polishing, sandblast external surface
8. Filtration precision: 1um - 100um
9. Material: SUS304, SUS316, SUS316L

Detail show:
Low Price 5 Micron Cartridge Filter with RO Plant Stainless Steel Filters Housing

Working principle
Precision filtration is to adopt the molding of filtration material, under the action of the pressure filtration material, make prefiltration through, stay in wall, phosphate-contained residue filtrate through filtering material flow, so as to achieve the purpose of filter.
Filtration material molding of filter cloth and filter are: , filter slice, sintering filter tubes, wire wound filter, melt-spurt filter core, etc. Because of the different filtration material, filtration aperture is not identical also. Precision filtration was between sand filter (coarse filter) and ultrafiltration between filtering, filtration aperture in commonly 0.5 ~ 120 mu m range. The same form of filtration material, press envelop dimensions can be divided into different specifications.
Wire wound filter (also called hive filter) has two kinds: One kind is polypropylene fibre - polypropylene skeleton cores, highest use temperature 60 ° C; Another kind is absorbent cotton fiber - stainless steel frame filter, the highest temperature. Use 120 ° C
Melt-spurt polypropylene filter is for raw material, adopting melt-spurt technology shaping filter material, the maximum operating temperature 60 ° C. Precision filter can remove the water the suspended material and fine, certain colloid particles, etc.

Application scope
1, nanofiltration (NF), ultrafiltration (UF), RO (RO), electrodialysis (EDI) system security filtration and terminal filter,
2, medicine injection, big transfusion, eye drops, Chinese herbal medicine, biological agents such as filtering liquor extraction, purification and concentration,
3, electronics, microelectronics, semiconductor industry with high pure water filtration, advance the terminal filtration,
4, oilfield waterflooding, back to the boiler make-up water, chemical reagent, liquid organic products, high purity chemicals, strong medicine such as filtering,
5, drinking pure water, mineral water, juice, tea beverages, health drink filtering,
6, liquor, wine, beer, yellow wine and other ratafia filtering, pure draft beer aseptic filtration (replacing pasteurising);
7, production and living in wastewater treatment and water recycling process of pretreatment filter or security filtering,
8 and other such as biological engineering, oil refining, printing and dyeing, textile industry of water and wastewater treatment, scientific experiment filtration and so on.

Model list
ModelDiameterWall thickness Filter core numberinlet/outlet portreferece flow
CK-10''*3coresΦ159mm1.2mm1-3cores1''0.75T/H
CK-20''*3coresΦ159mm1.2mm1-3cores1''1.5
CK-30''*3coresΦ159mm1.2mm1-3cores1''2.25
CK-40''*3coresΦ159mm1.2mm1-3cores1''3
CK-10''*5coresΦ195mm1.5mm3-5cores1''1.25
CK-20''*5coresΦ195mm1.5mm3-5cores1''2.5
CK-30''*5coresΦ195mm1.5mm3-5cores1.5''3.75
CK-40''*5coresΦ195mm1.5mm3-5cores1.5''5
CK-10''*7coresΦ230mm1.5mm5-7cores1''1.75
CK-20''*7coresΦ230mm1.5mm5-7cores1.5''3.5
CK-30''*7coresΦ230mm1.5mm5-7cores2''5.25
CK-40''*7coresΦ230mm1.5mm5-7cores2''7
CK-20''*9coresΦ273mm1.5mm9-10cores2''4.5
CK-30''*9coresΦ273mm1.5mm9-10cores2''6.75
CK-40''*9coresΦ273mm1.5mm9-10cores2''9
CK-20''*10coresΦ300mm1.5mm9-10cores2''5
CK-30''*10coresΦ300mm1.5mm10-12cores2''7.5
CK-40''*10coresΦ300mm1.5mm10-12cores2''10
CK-30''*12coresΦ325mm1.5mm12-15cores2''9
CK-40''*12coresΦ325mm1.5mm12-15cores2''12
CK-30''*15coresΦ350mm1.5mm15-17cores2''11.25
CK-40''*15coresΦ350mm1.5mm15-17cores2''15
CK-30''*20coresΦ400mm1.5mm20-22cores2.5''15
CK-40''*20coresΦ400mm1.5mm20-22cores2.5''20
CK-40''*25coresΦ450mm1.5mm30-35cores2.5''25
CK-40''*35coresΦ500mm2.0mm35-38cores3''35
CK-40''*45coresΦ600mm2.0mm40-45cores3''45
CK-40''*55coresΦ700mm2.0mm55-60cores4''55
CK-40''*85coresΦ800mm2.0mm80-85cores6''85
CK-40''*100coresΦ1000mm2.0mm90-100cores6''100

Packing&Delivery

Low Price 5 Micron Cartridge Filter with RO Plant Stainless Steel Filters Housing


Company Profile:
Low Price 5 Micron Cartridge Filter with RO Plant Stainless Steel Filters Housing


Guangzhou Chunke Environmental Technology Co., Ltd is a scientific enterpruise, which is specialized in water treatment equipment and accessories of research and development, production, sales and service.
Production and management: Cartridge filter, bag filter, mechanical filter, lon Exchanger, Imitation FRP barrels, ozone mixing tower, sterile water tank, stainless steel membrane shells, hollow-fiber mambrane, ultraviolet radiation sterialization device, ozone generator, and water treatment equipment and so on.

Tel: 86-020-86314618
Mobile : 86-18124265503
Fax: 86-020-22895083

Contact : Abby Ren

Website: chunke.en.made-in-china.com
Address: No.8, Suyuangzhuang, QingHu Village, Junhe Street, Baiyun District, Guangzhou. China

PS:Our company Molecular can customize different reverse osmosis system according to customers specific demand.
